products and solutions
| 设备型号 | 工作 厚度 (mm) |
加工宽度范围 (mm) |
输送带 速度(m/min) |
磨头数目 |
磨头电机 |
主传动 |
摆动电机 功率(kw) |
气源 |
单头 |
外形尺寸 (l×w×h) |
总 重 |
磨头类型 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
fm600b/8/9/10/12 |
5-20 |
300~600 |
10-24 |
8/9/10/12 |
11/15 |
11/15 |
2×4 |
0.6-0.8 |
20 |
9720/10370/11020/12320x2535x2705 |
14200/15000/15900/17500 | kd241a |
|
fm800b/8/9/10/12 |
5-20 |
400~800 |
10-24 |
8/9/10/12 |
11/15 |
11/15 |
2×4 |
0.6-0.8 |
20 |
9770/10620/11470/13170x2735x2705 |
15200/16000/16900/18500 | kd239c |
|
fm1000b/8/9/10/12 |
5-20 |
400/500-1000 |
10-24 |
8/9/10/12 |
11/15 |
11/15 |
2×4 |
0.6-0.8 |
20 |
11130/12150/13170/15210x2935x2705 |
16200/17000/17900/19500 | kd239c /kd239d |
| fm1200b/8/9/10/12 | 5-20 | 400/500/600-1200 | 10-24 | 8/9/10/12 | 11/15 | 11/15 | 2×5.5 | 0.6-0.8 | 20 | 11130/12150/13170/15210x3135x2705 | 17200/18000/18900/20500 | kd239c /kd239d /kd239e |
| fm1600b/9 | 5-20 | 800-1600 | 10-24 | 9 | 11/15 | 11/15 | 2×5.5 | 0.6-0.8 | 20 | 13250×3575×3250 | 27500 | φ 950齿轮盘 |
| fm1600b/10 | 5-20 | 800-1600 | 10-24 | 10 | 11/15 | 11/15 | 2×5.5 | 0.6-0.8 | 20 | 14350×3575×3250 | 29500 | φ 950齿轮盘 |
| fm2000b/9 | 5-20 | 800-2000 | 10-24 | 9 | 11/15 | 11/15 | 2×5.5 | 0.6-0.8 | 20 | 13250×4165×3250 | 32500 | φ 950齿轮盘 |
| fm2000b/10 | 5-20 | 800-2000 | 10-24 | 10 | 11/15 | 11/15 | 2×5.5 | 0.6-0.8 | 20 | 14350×4165×3250 | 34500 | φ 950齿轮盘 |
| fm1600db/9 | 5-20 | 800-1600 | 10-24 | 9 | 22 | 11/15 | 2×5.5 | 0.6-0.8 | 20 | 13250×3575×3250 | 27500 | φ 950小电机 |
| fm1600db/10 | 5-20 | 800-1600 | 10-24 | 10 | 22 | 11/15 | 2×5.5 | 0.6-0.8 | 20 | 14350×3575×3250 | 29500 | φ 950小电机 |
| fm1800db/9 | 5-20 | 800-1800 | 10-24 | 9 | 22 | 11/15 | 2×5.5 | 0.6-0.8 | 20 | 13250×2950×3250 | 32500 | φ 950小电机 |
| fm2200db/12 | 5-20 | 800-2200 | 10-24 | 12 | 22 | 11/15 | 2×12 | 0.6-0.8 | 20 | 16550×3350×3250 | 34500 | φ 950小电机 |
